Product Introduction
The PVC High Speed Roller Shutter Door with Thermal Insulation combines rapid opening with improved separation for areas that need temperature stability. It helps reduce open-door time, supports energy control and keeps traffic routes moving in warehouses, workshops and clean industrial environments.
Product Description
Highlights at a glance
- High Speed Operation: Quick opening/closing for efficient workflow.
- Thermal Insulation: Keeps indoor temperature stable, reducing energy costs.
- Modern Design: Sleek appearance enhances workshop aesthetics.
- Durable Finish: Resistant to wear and tear, ensuring long-lasting use.
- Customizable Colors: Available in various shades to match your workspace.
Technical Specifications
| Door panel material | High density PVC fabric curtain with reinforced windproof ribs |
|---|---|
| Curtain color | Yellow, orange, blue, grey, red, white, green or customized color |
| Visual window(optional) | High quality transparent PVC vision window |
| Hardware material | #304 stainless steel, ensure high quality |
| Door opener | Three kinds for choice: 1) Servo motor,0.75-1.5KW, 50-60HZ 2) SEW motor:0.75-2.2KW, 50-60HZ 3) SEJ motor:0.9-2.2KW, 50-60HZ |
| Running speed | 0.8-1.5m/s, can be adjustable |
| Sensors | Standard: photocell, radar, and push button Optional: loop detector, remote control, light curtain sensor, safety airbag, magnetic card, pull cord |
| Max size | W9000mm*H8000mm, If over this size, we can recommend our another flexible double layer high speed folding door |
| Working condition | -40°C to 70°C |
| Wind resistance | 60-80km/h, folding type has better windproof function |
| Application | Warehouses, Temperature-controlled workshops, Factories, Logistics centers |
| Warranty | 1 year for electric parts, 5 years for mechanical parts |
| Insulation | Insulated panel or thermal configuration depends on the selected door model and project requirement. |
Details Images
Drawing
Curtain color for choice
Motor and control box
Control system for choice
Operation way and safety device
Manual mode: push button
press “up” button--door open--forklift go through--press “down”button--door close
Auto mode: radar, loop detector, light curtain sensor, etc
Semi-auto mode: pull cord, magnetic card, remote control
Packing & Delivery
Optional Configurations
- Insulated curtain material
- Transparent vision panel
- Radar sensor
- Loop detector
- Air curtain linkage
FAQ
Where is PVC High Speed Roller Shutter Door with Thermal Insulation commonly used?
PVC High Speed Roller Shutter Door with Thermal Insulation is commonly used for warehouses, temperature-controlled workshops, factories, logistics centers where fast opening and controlled access are required.
What information is needed before quotation?
Please send opening width, opening height, quantity, application, operation preference, site photos if available and destination country.
